Applicable materials: BOPP, COPP, PET, PVC, nylon and other plastic composite films, multi-layer co-extruded films, aluminized composite films, paper-plastic composite films, pure aluminum foil composite films, etc.
Technical Parameters：
|
Model |
MHZD-1300E |
|
Maximum diameter of unwinding |
Ф800mm |
|
Maximum width of roll film |
1320mm |
|
Maximum pulling length/time |
600mm |
|
Highest beat |
30PCS/Min |
|
Number of unwinding systems |
6 sets |
|
Maximum unwinding speed |
20M/Min |
|
Maximum pulling length |
600mm×1/2/3/4/5/6 |
|
Maximum bag making width |
1300mm |
|
Bag making speed |
≤25L: 13 bags×2 |
|
220L: 3 bags |
|
|
Positioning accuracy |
≤±0.3mm |
|
Quantity of heat sealing and cooling knives |
20 pieces |
|
Temperature control quantity |
12 channels |
|
Servo system |
6 sets |
|
Temperature setting range |
room temperature ∽ 400℃ |
|
Whole machine power |
65KW |
|
Dimensions |
18500X3500X2200MM |
