Applicable base materials: BOPP, COPP, PET, PVC, nylon and other plastic composite films, multilayer co-extruded films, aluminum composite film, paper plastic composite film, pure aluminum foil composite film.
Technical Parameters
Voltage: 380v, 50Hz, power 48kw
Roll film diameter: 800mm
Max film width: 1220mm
Sleeve diameter: 3 inches
Package width: 100-600 mm
Pull length/times: 30-400mm(×2，×3……8)
Positioning Accuracy: ≤±0.3mm
Speed: 130 pcs(or 36 meters)
Dimensions: 10500X2000X1900MM
Weight: 4000 kg
